Started working on the control layout. First step was to do some sketching. A lot of the individual parts have already been fabricated but I wanted to start thinking of how those parts come together to help form the cockpit. I say cockpit because I want it to have a definite aircraft influence.

The steering wheel was first on my agenda. The horn button was scavenged from the Camaro,before I sold it, and I had an idea how I wanted to incorporate it into this project. There is a pic of it in this tread. I have the aluminum for the hub and can't wait to start cutting it. I haven't decided whether or not the spokes will be 3D modeled and CNC cut, or clay modeled and cast; but they will be TIG welded to the hub. The rim is steel, from a 12-inch aftermarket el cheapo steering wheel. I haven't decided whether it will be painted, covered with carbon fiber, or stitched with leather.

The shifter knob and gate plate both exist, and pics of them have also been posted in this thread. The shifter is the one directly under the steering wheel rim and spokes. The other one is the emergency brake. I have already fabricated the aluminum arm and a large ball knob for it, but not the mechanism. I haven't really even given any serious thought to how I am going to make the mechanism. I just want it there. Most of the early twentieth-century vehicles had a bunch of levers and knobs coming up off the floor.

A pic of the pedal assembly was also posted here. The support arm for the steering shaft has also been roughed in already. I still have to turn the piece the sleeve passes through and have it TIG'd on the arm though. It will have an oil-impregnated bronze bushing pressed in either end. The shaft will be stainless.

My thinking for the overall look, right now, is to "float" all these fabricated aluminum parts over a sculptured carbon fiber tub that extends about halfway up to the top of the body. The top half would be painted and/or leather covered. Just thoughts right now that need to be sketched and modeled to work out.

------------------
