IMSA widebody installation - Russ style by Russ544
Started on: 08-29-2004 11:36 PM
Replies: 555 (56219 views)
Last post by: Rickady88GT on 02-06-2018 11:55 PM
Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post08-29-2004 11:36 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

Seems to be some interest in following along as I do this widebody kit, so I keep posting as long as people keep watching I guess. I'll be doing this a bit different than some others have in the past, and perhaps if it comes out well we can even talk Sage into re-doing the molds a bit to save others some work. IMHO a race inspired car should look like a race car, and those tiny wheel openings on the street version of the IMSA with 215x14 tires just dont look like race material to me so I'll be opening those up to allow for some serious rubber to meet the road. I also ordered my kit "wing deleat" and had Tedd make me up some 5" wing stands for a stock type wing.... but that's just my preference.
BTW: here is some info on the 4.3L Chev that powers the car:
http://www.fiero.nl/forum/Forum1/HTML/044164.html

So without further ado........... First we gota get nekid.

This has been covered numerous times so I won't go into how the old cloths come off, but it's a fairly simple matter and should only take about a half day for a first timer.



We'll be re-using the substructure from the rear clip and a small portion of the original skin. Start by cutting just deep enough to go through the skin without damaging the substructure under it. When I did this step I hadn't received the IMSA parts yet, so I left much more of the old skin than I needed to, but you'll want to cut closer to the red lines. It's hard to see in the photo, but all but about 1 1/2" on each end of the rear "tray" will be re-used as well.



Carefully pry loose the sides with whatever tools you have handy, but the key is to go slow and try to only sacrafice the old skin and not the substructure that needs to be re-used. Fortunatly the substructure seems to be a stronger material, so it's not as hard as it sounds.



A couple of alteration will need to be done to the rear bumper area. About 2" needs to be cut off each end to clear the mating flange where the rear fenders and rear facia join. A small portion of the rear facia support tray needs to come off also, and the old lower facia support hardware can hit the dumpster as well.
I found out the hard way that once the IMSA rear fenders and facia are permanently joined, it becomes imposible to remove the rear clip as you can no longer lift the rear of the clip up that few inches needed to free the three roof studs. You can laugh at me later when you see what I had to do to remove the bumper bolts with the clip on the car, but just trust me for the meantime and cut about a 2" x 6" piece out of the lower ends of the bumper where noted in green before you glue the parts together .



To be continued:

[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

Electrathon
Member

Posts: 5233
From: Gresham, OR USA
Registered: Dec 2002


Feedback score:    (39)
Leave feedback





Total ratings: 254
Rate this member

Report this Post08-29-2004 11:52 PM Click Here to See the Profile for ElectrathonClick Here to visit Electrathon's HomePageClick Here to Email ElectrathonSend a Private Message to ElectrathonEdit/Delete MessageReply w/QuoteDirect Link to This Post

Russ,

Is that my old 85?

Cool build too. For those that are not aware Russ deos great looking work.

Aaron

IP: Logged

gascarracer
Member

Posts: 129
From: Batavia, Ohio, USA
Registered: Apr 2003


Feedback score: N/A
Leave feedback

Rate this member

Report this Post08-30-2004 12:37 AM Click Here to See the Profile for gascarracerClick Here to Email gascarracerSend a Private Message to gascarracerEdit/Delete MessageReply w/QuoteDirect Link to This Post

Great start. Keep up the good work.


Thanks!!!!


------------------
Ernie

1988 Silver GT
One owner 47000 miles.
Soon to be a 3.4 DOHC powered.

IP: Logged

Vonov
Member

Posts: 3745
From: Nashville,TN,USA
Registered: May 2004


Feedback score: N/A
Leave feedback





Total ratings: 84
Rate this member

Report this Post08-30-2004 01:54 AM Click Here to See the Profile for VonovClick Here to Email VonovSend a Private Message to VonovEdit/Delete MessageReply w/QuoteDirect Link to This Post

Drooling so much over this one, I feel almost like I should be looking over my shoulder for the Vice Squad...great start, keep it coming. The fish will wait, and grow bigger in the meantime too...yeah, that's it...let dem fish grow.

------------------
88 Formula, "Asphalt Aviator"

Celebrate Artesian New Year!!!

IP: Logged

NotAFieroAnyLonger
Member

Posts: 4413
From: 75762/Texas/USA
Registered: Dec 2003


Feedback score: N/A
Leave feedback





Total ratings: 255
Rate this member

Report this Post08-30-2004 01:58 AM Click Here to See the Profile for NotAFieroAnyLongerClick Here to Email NotAFieroAnyLongerSend a Private Message to NotAFieroAnyLongerEdit/Delete MessageReply w/QuoteDirect Link to This Post

I love thread's like these... Thank's for sharing!!

------------------
*Custom-Shaved HandBuilt!!*
*First Chopped-WidebodyGT!!*

*~*going 4.9L*~*Pic's Coming Soon!Stay Tuned!!

IP: Logged

FieroRumor
Member

Posts: 35007
From: New York
Registered: Dec 2001


Feedback score: (2)
Leave feedback





Total ratings: 350
Rate this member

Report this Post08-30-2004 04:24 PM Click Here to See the Profile for FieroRumorClick Here to visit FieroRumor's HomePageClick Here to Email FieroRumorSend a Private Message to FieroRumorEdit/Delete MessageReply w/QuoteDirect Link to This Post

Cool!

*adds this thread to favorites*

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post08-31-2004 12:39 AM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

Thanks guys.
I was gona use your 85 Aaron, but at the last minute I decided to use this 88 coupe I had laying around. this is also the car that I built and installed the 4.3L into, so it should be a fun ride
================

CHAPTER 2:

Before trial fitting of the rear fenders and facia begin you'll want to set them on the floor and carefully align the parts wile you drill 4 or 5 1/4" holes in each flange and bolt them together. it's much easier to do this off the car. When you're satisfied with the alignment of the parts you can remove the bolts and set them aside for now.

After setting what's left of the rear clip back on the car, you can begin trial fitting of the fenders and rear facia to locate areas of the substructure that will need slight trimming. The thickness of the new fiberglass parts require that you do some slight trimming of the substructure to allow them to fit over it. The areas that I found necessary to trim are noted in red. I removed the tab near the door ( the IMSA fenders have a tab that replaces this tabs function), and trimmed about 1/8" off the other areas. the red dots indicate that the area trimmed was on the inside edge and not actually visible in the photo. Each body will no doubt be slightly different, but this should give you the general idea.




The better the fit of the IMSA parts on the substructure the less bodywork will be required to fill any gaps and smooth the transitions, so spend plenty of time on this phase. When you have everything fitting as well as you think you can, install a couple bolts in each flange and check some more. fitting and adjusting until the parts feel like they belong together. Once the parts are glued together you can't come back and adjust anymore !!! When the parts fit on the substructure to your satisfaction it's time to reinstall the rear decklid to check the gaps between it and the fenders, and to locate the two screw holes in each side that retain the top of each fender. I placed a piece of tape over each of the original fender mounting holes on the chassis and drew a line on it to indicate center. At a marked distance out from the hole I drew a crosshair over the line so when the new fender is installed, and covers the hole, you still know exactly where the hole needs to be drilled in the IMSA fender to line up with the chassis hole (it's easier than I make it sound ). With the rear decklid installed you can check the gaps along the fenders, and when the're straight and equal on each side, you can drill the mounting holes in the fiberglass.




When you're comfortable with the fit of the parts on the substructure and have checked that the gaps at the door and rear deck are straight and not too wide or narrow, and holes are drilled in the top of the fender flange........ you're almost ready to commit to the glue. I highly recommend 3M panel bond adhesive #8115 (thanks for the tip Sage). It gives the needed working time to get everything aligned and provides excellent strength and flexibility. A special applicator is needed for this, but most automotive paint suppliers who sell this product will loan you the applicator gun. One 200ml cartridge will JUST be enough to join all of the rear clip components. (also available at handsontools.com if you prefer online purchase)

Place the substructure on the car and have all your tools, nuts and bolts, adhesive, cleaning solvent, rags, and whatever else you might need in a handy place next to the car so you don't have to chase all over for them wile the adhesive is setting up. You should have plenty of time to work, but not a great deal to spare chasing tools, so prepare for battle early.
The areas noted in yellow below are the only points that make contact between the substructure and the IMSA fenders, and are therefore also the places to place a generous amount of adhesive. Set one fender and quickly pull it off again to see where the adhesive has made contact. you can add more adhesive to areas now that didn't make contact. set the fender again and bolt on the rear facia using adhesive this time on the flanges, then on to the other fender. use clamps to hold the roof section in alignment and recheck for rear decklid and door alignment as you install the upper fender mounting bolts.
Once the rear clip is glued on you can take a day off to drink beer and watch the Speed Channel wile the adhesive cures. you earned it



[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

gumert
Member

Posts: 400
From: Hunderton, NJ
Registered: Mar 2004


Feedback score: N/A
Leave feedback





Total ratings: 78
Rate this member

Report this Post08-31-2004 01:02 AM Click Here to See the Profile for gumertClick Here to Email gumertSend a Private Message to gumertEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote

sexy

[This message has been edited by gumert (edited 08-31-2004).]

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post08-31-2004 09:58 AM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by gumert:


sexy



It's gona get even better soon. note line around wheel opening

[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

MinnGreenGT
Member

Posts: 11484
From: Lakeville, MN 55044
Registered: Jul 2001


Feedback score: (1)
Leave feedback





Total ratings: 275
Rate this member

Report this Post08-31-2004 10:01 AM Click Here to See the Profile for MinnGreenGTClick Here to visit MinnGreenGT's HomePageClick Here to Email MinnGreenGTSend a Private Message to MinnGreenGTEdit/Delete MessageReply w/QuoteDirect Link to This Post

Excellent write-up ...keep 'em coming (we're watching)!

------------------

Looking for Fiero posters?

IP: Logged

DPWood
Member

Posts: 540
From: Aylmer, Ont. Canada
Registered: May 2002


Feedback score: N/A
Leave feedback

Rate this member

Report this Post08-31-2004 11:05 AM Click Here to See the Profile for DPWoodClick Here to visit DPWood's HomePageClick Here to Email DPWoodSend a Private Message to DPWoodEdit/Delete MessageReply w/QuoteDirect Link to This Post

This has a seriously high cool factor. I've always loved the lines of the Fiero IMSA flares. Now I get to see every step that goes into the finished product. This thread goes into my favourites.

BIG + for you...

David

------------------
His Fiero: 1984 2M4 Coupe

Her Fiero: 1984 2M4 Convertible

IP: Logged

FieroMGDriver
Member

Posts: 961
From: Concord, NC USA
Registered: Nov 2001


Feedback score: N/A
Leave feedback

Rate this member

Report this Post08-31-2004 01:05 PM Click Here to See the Profile for FieroMGDriverClick Here to Email FieroMGDriverSend a Private Message to FieroMGDriverEdit/Delete MessageReply w/QuoteDirect Link to This Post

What are your plans for the vents behind the doors? Mesh? Oil cooler, tranny cooler?

------------------
-Matthew
87 GT My transportation
86 GT My headache

IP: Logged

Will-Martin
Member

Posts: 1164
From: DFW, TX, USA
Registered: Aug 2002


Feedback score: (1)
Leave feedback





Total ratings: 63
Rate this member

Report this Post08-31-2004 03:36 PM Click Here to See the Profile for Will-MartinClick Here to visit Will-Martin's HomePageSend a Private Message to Will-MartinEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Russ544:


It's gona get even better soon. note line around wheel opening

Nice, that and chopping the top are the 2 things I would do to an IMSA Widebody.

Good job man!

IP: Logged

R Runner
Member

Posts: 3554
From: Bowling Green, KY USA
Registered: Feb 2003


Feedback score:    (12)
Leave feedback





Total ratings: 98
Rate this member

Report this Post08-31-2004 09:56 PM Click Here to See the Profile for R RunnerClick Here to visit R Runner's HomePageClick Here to Email R RunnerSend a Private Message to R RunnerEdit/Delete MessageReply w/QuoteDirect Link to This Post

Yeeeeesssssss! Nice. This is a great thread. I agree completely, it needs to look like a race car. Good for you!

------------------
Paul

645hp Tube Chassis IMSA Race Car | 96 T/A WS6 - 5100 miles | 87 GT Old Daily Driver - 229,xxx , 800rms sound system, autox suspension (FOR SALE) | Blue 87 GT New Daily Driver - 116,xxx, 3.1 motor, 1 1/4" rear swaybar

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post08-31-2004 10:24 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by R Runner:

Yeeeeesssssss! Nice. This is a great thread. I agree completely, it needs to look like a race car. Good for you!

BTW R Runner, Are you using the 5 x 100 bolt pattern on your IMSA? I've been looking for some Nascar style rims like you're using but can't find anything with decent offset in the 5 x 100 pattern. Any ideas?

Thanks,
Russ

FieroMGdriver,
I haven't given a lot of thought to the fate of the fender vents, but I'll most likely open them up at some point. The 88 chassis I'm using has the fuel "burp" tank behind the right side and the fuel fill pipes behind the left, so that limits the vents functionality somewhat. From my experience with my SBC car I've found that it's very benificial to have all the cool air in the engine bay you can get, so that will most likely be the goal on this car as well however.

[This message has been edited by Russ544 (edited 08-31-2004).]

IP: Logged

88GTFormula
Member

Posts: 2721
From: mont Alto
Registered: May 2004


Feedback score:    (9)
Leave feedback

Rate this member

Report this Post09-01-2004 12:50 AM Click Here to See the Profile for 88GTFormulaClick Here to Email 88GTFormulaSend a Private Message to 88GTFormulaEdit/Delete MessageReply w/QuoteDirect Link to This Post

Yea, This is in my favorites... like definatly... lol

I would like to do this, except with a chopped fastback...

~Tim

------------------

http://www.cardomain.com/memberpage/610461

AIM: Fierofreek8488

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-01-2004 10:13 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

CHAPTER 3:

After the adhesive has cured overnight, you can lift the rear clip back off for some finish work. Begin by checking to see that the adhesive has made good contact at all points, and add more to fill any gaps. I used 3M #8227 SMC/Fiberglass adhesive for this as it has a much faster cure time than the panel adhesive. The fender/rear Facia below the rear flange needs to be joined with a bit of fiberglass and resin (note red arrow), and you can place a small reinforcement inside the exposed roof seam edges with the leftovers as well.




This is a good time to do some body work to fill and smooth the exterior seams, and clean up any raged fiberglass edges. The inner sail panels may need some minor fitting and trimming of the edge that mates up with the new fiberglass, but 10 minutes with a bench grinder should take care of both sides.
BTW: If you forgot to cut out the notch on the lower ends of the rear bumper as noted back in chapter 1, I've convieniently drilled 1 1/2" holes in the rear of this clip just to point out where the holes need to be drilled to gain access to the bumper bolts you'll need to take out in order to remove the rear clip once it's all permanently joined together........ Not that I would ever forget to do that myself




I'll be doing a couple modifications on the rear clip at this point which aren't part of the normal installation, but that's why I call this "Russ style". As I mentioned earlier, I want to open up the wheelwells in order to install some larger tires. The size hasn't been finalised yet, but this looks about right to me:




I also plan to extend the fuel fill pipe in order to bring it back up to the level of the new flared fender, and trim open the IMSA fiberglass in order to reinstall the stock Fiero flip open fuel door. I have a 4 day weekend coming up, so perhaps I'll get those things taken care of and written up soon.

[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

Will
Member

Posts: 12621
From: Where you least expect me
Registered: Jun 2000


Feedback score: (1)
Leave feedback





Total ratings: 233
Rate this member

Report this Post09-01-2004 10:17 PM Click Here to See the Profile for WillClick Here to Email WillSend a Private Message to WillEdit/Delete MessageReply w/QuoteDirect Link to This Post

Mitsubishi Eclipse gas cap? Those look cool

You ought to have enough extra width to run 335/35-17's

------------------
Punch the gas and feel the back step sideways; rip off a powershift and hear the tires punished by torque; downshift, lift off and feel the engine braking that comes only from big cubes, listen to the pop and gurgle. Know that you are driving an American V8. There are finer engines made, but none that are this cool.

Luck, Fate and Destiny are words used by those who lack the courage to define their own future

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-01-2004 10:28 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Will:

Mitsubishi Eclipse gas cap? Those look cool

You ought to have enough extra width to run 335/35-17's

Sounds good to me . But first I need to find some Nascar style rims in the offset and width I need.
BTW. I like the last line of your sig. Wasn't it a race driver who once said, when acused of just being a lucky winner: "yes, and the more I practice, the luckier I get".

IP: Logged

Will
Member

Posts: 12621
From: Where you least expect me
Registered: Jun 2000


Feedback score: (1)
Leave feedback





Total ratings: 233
Rate this member

Report this Post09-02-2004 09:08 AM Click Here to See the Profile for WillClick Here to Email WillSend a Private Message to WillEdit/Delete MessageReply w/QuoteDirect Link to This Post

Have you figured out the width and offset yet? According to WCF, a 17x9-45 will fit the stock suspension and body work. Based on looking at my car, I think a 17x9-38 would work as well. You've got 4 extra inches of width on each side, right? 9+4 = 13... which is pretty good for a 335. The resulting offset would be about 60mm in the opposite direction, or 17x13+60 (maybe +55ish). That's a pretty wild wheel. The positive offset will reduce wheel bearing loads in hard cornering.

------------------
Punch the gas and feel the back step sideways; rip off a powershift and hear the tires punished by torque; downshift, lift off and feel the engine braking that comes only from big cubes, listen to the pop and gurgle. Know that you are driving an American V8. There are finer engines made, but none that are this cool.

Luck, Fate and Destiny are words used by those who lack the courage to define their own future

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-02-2004 10:05 AM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Will:

Have you figured out the width and offset yet? According to WCF, a 17x9-45 will fit the stock suspension and body work. Based on looking at my car, I think a 17x9-38 would work as well. You've got 4 extra inches of width on each side, right? 9+4 = 13... which is pretty good for a 335. The resulting offset would be about 60mm in the opposite direction, or 17x13+60 (maybe +55ish). That's a pretty wild wheel. The positive offset will reduce wheel bearing loads in hard cornering.

I haven't determined wheel sizes yet, but I need to take some time and do that here pretty soon. I may end up making or buying wheel adaptors so I can get wheels of my liking on the 5 x 100 pattern. The original 84 race IMSA had 345 35 15 on the rear and 225 60 15 on the front, so I've been kind of using that as a general guide as to what fits and looks right.

IP: Logged

MinnGreenGT
Member

Posts: 11484
From: Lakeville, MN 55044
Registered: Jul 2001


Feedback score: (1)
Leave feedback





Total ratings: 275
Rate this member

Report this Post09-02-2004 11:08 AM Click Here to See the Profile for MinnGreenGTClick Here to visit MinnGreenGT's HomePageClick Here to Email MinnGreenGTSend a Private Message to MinnGreenGTEdit/Delete MessageReply w/QuoteDirect Link to This Post

Lookin' great... about the gas door thing. I had originally planned on using an Izuzu VehiCross (aircraft-style) gas door (it's flatter and closer in size/shape than the Audi or Eclipse doors), but have since changed my mind. LMK if you're interested - I paid around $75-$85 for the parts I've got... I'd let 'em go for about $25 shipped.


http://www.fiero.nl/forum/Archives/Archive-000002/HTML/20020511-1-012834.html

IP: Logged

2.8-4spd
Member

Posts: 181
From: Cincinnati,Ohio,USA
Registered: Oct 2001


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-02-2004 08:47 PM Click Here to See the Profile for 2.8-4spdClick Here to Email 2.8-4spdSend a Private Message to 2.8-4spdEdit/Delete MessageReply w/QuoteDirect Link to This Post

Minngreen GT iF they they dont want it, I will take it, do you take paypal?

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-02-2004 11:07 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by 2.8-4spd:

Minngreen GT iF they they dont want it, I will take it, do you take paypal?

No problem Minn. I already have other plans for my system, so if you want to sell this go ahead.
Thanks for the offer however.

Russ

IP: Logged

MinnGreenGT
Member

Posts: 11484
From: Lakeville, MN 55044
Registered: Jul 2001


Feedback score: (1)
Leave feedback





Total ratings: 275
Rate this member

Report this Post09-03-2004 09:57 AM Click Here to See the Profile for MinnGreenGTClick Here to visit MinnGreenGT's HomePageClick Here to Email MinnGreenGTSend a Private Message to MinnGreenGTEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Russ544:

No problem Minn. I already have other plans for my system, so if you want to sell this go ahead.
Thanks for the offer however.

No problem... just though I'd offer. I'm Looking forward to seeing more pics of your work!


quote
Originally posted by 2.8-4spd:

Minngreen GT iF they they dont want it, I will take it, do you take paypal?

Looks like it's yours (I got your email as well). You can PayPal to that same address...

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-03-2004 09:42 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

CHAPTER 4:
(The "Russ style" part)

In order to enlarge the wheelwells a small air reciprocating saw makes quick work of the fiberglass:




To replace the lip, A thin piece of sheet aluminum is hammered to form a "mold" to support the new glass and resin. By rolling the edge, the contours can easily be blended into the fender, eliminating a lot of grinding and filling later on. An old sign provides a good source for cheep aluminum of suitable thickness, and is easily formed to the proper curve and taped onto the wheel opening after spraying the back side with wax:




Once the form has been set, and fully taped, you can flip the rear clip right side up again and lay in several layers of glass onto the form, and an inch or two up the side. Pretty simple actually, and after it cures for a day I'll pull off the tape and aluminum strip and do some bondo work to finish it off.

Now THIS is a proper size wheelwell for a "race" car

[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-04-2004 10:38 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

CHAPTER 4 +
Although it feels like I worked plenty hard enough, I didn't seem to make much headway today. I am, however, pretty happy with the results of the fiberglass work on the wheelwells. After the aluminum strips came off, It didn't take too much body work to smooth out the minor irregularities and fill a few small voids. It does, however, make me appreciate just how good the fiberglass work is that Tedd (Sage) did on this body kit. I've yet to find a void in his layup bigger than a pin head or two. Pretty amazing IMHO.



[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

BtotheB
Member

Posts: 2579
From: Peterborough, Ontario
Registered: Dec 2001


Feedback score: (1)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-05-2004 10:37 AM Click Here to See the Profile for BtotheBClick Here to visit BtotheB's HomePageClick Here to Email BtotheBSend a Private Message to BtotheBEdit/Delete MessageReply w/QuoteDirect Link to This Post

Very cool thread. I love seeing this kinda stuff coming together... good stuff!

Brad

------------------

IP: Logged

gascarracer
Member

Posts: 129
From: Batavia, Ohio, USA
Registered: Apr 2003


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-12-2004 11:55 AM Click Here to See the Profile for gascarracerClick Here to Email gascarracerSend a Private Message to gascarracerEdit/Delete MessageReply w/QuoteDirect Link to This Post

Whats up? Is this on hold. I am really interested in this thred. Plan to do this sooner or later.

------------------
Ernie

1988 Silver GT
One owner 47000 miles.
Soon to be a 3.4 DOHC powered.

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-12-2004 05:55 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

No huge progress to report for this week as I've had a lot of other business to attend to.... and not much time to devote to the important stuff .....
I did get the finish body work on the rear clip pretty much done however..... seams molded in etc.. I also managed to get the hood vents cut in and in primer, and I've opened up the front wheel wells about an equal amout as I did to the rears. The fronts don't have the flanges in yet as I forgot to order more resin last week, and I refuse to use the stuff you can buy at Wally world etc.. "If it's worth doing.... it's worth doing right".
The car will get lowered, as well as receiving fatter rubber on wide rims, but with some imagination it's getting easier to see what it's becoming now.





Stay tuned for updates. don't give up on me just yet

Russ

[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

fierogt4e
Member

Posts: 119
From: up state New York
Registered: Mar 2003


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-13-2004 12:55 AM Click Here to See the Profile for fierogt4eClick Here to Email fierogt4eSend a Private Message to fierogt4eEdit/Delete MessageReply w/QuoteDirect Link to This Post

WOW!!!!
HOLY SH##
You have blown my F&&&ing mind.
I have also done this to my IMSA (85 GT/4E)
I am very excited to see another person customizing and updating this body style
I realy want to see what you will do next to refine the body and thanks for showing it to us.
VERY cool indead !
------------------
Sincerely
George
www.switch-tray.com

edit; used words instead of photos

[This message has been edited by fierogt4e (edited 09-15-2004).]

IP: Logged

Vonov
Member

Posts: 3745
From: Nashville,TN,USA
Registered: May 2004


Feedback score: N/A
Leave feedback





Total ratings: 84
Rate this member

Report this Post09-13-2004 02:43 AM Click Here to See the Profile for VonovClick Here to Email VonovSend a Private Message to VonovEdit/Delete MessageReply w/QuoteDirect Link to This Post

Can you say Bad-axe notchback??? Nice pix...I like the blue and white too...

Back to our host...take it away, Russ...

------------------
88 Formula, "Asphalt Aviator"

"I've seen em---they're little fellers. You know, the Artesians..."
---caretaker at Olympia Brewery

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-17-2004 10:15 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

Another abbreviated chapter today, but I have two days ahead of me with no obligations other than working on the IMSA project so perhaps a better chapter will follow by Monday.
Today I worked out a solution for the fuel filler, which with the IMSA fender becomes recessed about 4" deeper, and lacks any provision for an outer fuel door. my trusty air reciprocating saw was used to remove the abbreviated cup provided (taped back into the fender for this photo).

I wanted to utilize the Fiero flipper door, so some modifications were in order. I first thought of extending the metal fuel tube, but upon more detailed investigation I found it to be more work than I was willing to devote to it. The new filler opening doesn't line up with the old filler well enough to simply extend the metal pipe without a tricky curve. but by carefully removing most of the bottom of the fuel filler "cup", ......

there is now room to reach the fuel cap without too much effort.
The areas originally used to secure the fuel cup to the fender are now out of reach, so I plan to bond my modified fuel cup, which retains areas used to support the cover latch and hinge mechanisms, to the fiberglass fender with the same 3M body panel adhesive used to attach the substructure to the rear clip fiberglass. Now when the filler door gets reinstalled everything will function the same as the stock unit, compleat with interior door release.


<front facia and fender installations come next>

[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

NotAFieroAnyLonger
Member

Posts: 4413
From: 75762/Texas/USA
Registered: Dec 2003


Feedback score: N/A
Leave feedback





Total ratings: 255
Rate this member

Report this Post09-18-2004 02:34 AM Click Here to See the Profile for NotAFieroAnyLongerClick Here to Email NotAFieroAnyLongerSend a Private Message to NotAFieroAnyLongerEdit/Delete MessageReply w/QuoteDirect Link to This Post

Lookin' GREAT Russ!!

------------------
----------------------------------
*Custom-Shaved HandBuilt!!*
*FIRST-EVER CHOPTOP-WIDEBODY GT!!*

(( 4.9L-V8-5speed)) swap soon
-----------------------------------------------

IP: Logged

Will
Member

Posts: 12621
From: Where you least expect me
Registered: Jun 2000


Feedback score: (1)
Leave feedback





Total ratings: 233
Rate this member

Report this Post09-18-2004 07:39 AM Click Here to See the Profile for WillClick Here to Email WillSend a Private Message to WillEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Russ544:
The areas originally used to secure the fuel cup to the fender are now out of reach, so I plan to bond my modified fuel cup, which retains areas used to support the cover latch and hinge mechanisms, to the fiberglass fender with the same 3M body panel adhesive used to attach the substructure to the rear clip fiberglass. Now when the filler door gets reinstalled everything will function the same as the stock unit, compleat with interior door release.

Just out of curiosity, once you do that, are you going to be able to remove the rear clip, should it be required at some point in the future?

------------------
Turn the key and feel the engine shake the whole car with its lope; Plant the gas pedal and feel in your chest neither a shriek nor a wail but a bellowing roar; Lift and be pushed into the harness by compression braking that only comes from the biggest cylinders while listening to music of pops and gurgles. Know that you are driving and American V8. There are finer engines made, but none of them are this cool.

Luck, Fate and Destiny are words used by those who lack the courage to define their own future

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-18-2004 10:20 AM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Will:


Just out of curiosity, once you do that, are you going to be able to remove the rear clip, should it be required at some point in the future?

Yes. even though it's bonded to the body panel now, the fuel filer "cup" has had it's base removed so it no longer captures the metal fuel filler tube (plus the metal filler is now below where the base was anyway). The three sheet metal screws which retain the metal fuel tube to the rear clip substructure can still be removed if one should need to pull the rear clip.

Russ

[This message has been edited by Russ544 (edited 09-18-2004).]

IP: Logged

gascarracer
Member

Posts: 129
From: Batavia, Ohio, USA
Registered: Apr 2003


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-18-2004 11:52 AM Click Here to See the Profile for gascarracerClick Here to Email gascarracerSend a Private Message to gascarracerEdit/Delete MessageReply w/QuoteDirect Link to This Post

You are doing a fantasic job. Keep it comming. Thanks.

------------------
Ernie

1988 Silver GT
One owner 47000 miles.
Soon to be a 3.4 DOHC powered.

IP: Logged

blackrams
Member

Posts: 27337
From: Frankfort, KY, USA
Registered: Feb 2003


Feedback score:    (7)
Leave feedback





Total ratings: 217
Rate this member

Report this Post09-18-2004 04:53 PM Click Here to See the Profile for blackramsClick Here to Email blackramsSend a Private Message to blackramsEdit/Delete MessageReply w/QuoteDirect Link to This Post

Outstanding thread, has given me several ideas that may get used on my Pantero project. Hope you don't mind. The gas filler is one that I've been trying to figure out. Keep up the great work.

------------------
Ron
aka: Blackrams

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-18-2004 06:47 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by blackrams:

Outstanding thread, has given me several ideas that may get used on my Pantero project. Hope you don't mind. The gas filler is one that I've been trying to figure out. Keep up the great work.

Glad to hear people are getting some usefull info and ideas out of this.
The process of observing others creations and then devising "but I'd do this part a little different here" ideas is what hot rodding is all about IMHO.

IP: Logged

Russ544
Member

Posts: 2136
From: S.W. Oregon
Registered: Jun 2003


Feedback score: (3)
Leave feedback





Total ratings: 86
Rate this member

Report this Post09-18-2004 11:40 PM Click Here to See the Profile for Russ544Send a Private Message to Russ544Edit/Delete MessageReply w/QuoteDirect Link to This Post

CHAPTER 7
Not a bad day........ The front wheel openings received an enlargement similar to the rears, but the same process as used on the rear, with the temporary aluminum strip "molds", was used to replace the lip in the front wheel opening so I won't repeat those details.

Wile the resin set up on the fenders I went ahead and permanently secured the rear clip. It took 18 1/4" rivets and 7 bolts, + the 8 bolts/nuts that hold the rear facia and fenders to one another, so she's solid as a rock now !

I had originally intended to paint the parts individually, but for a variety of reasons I've decided to change my assembly process, requireing that I paint everything except the front and rear decklids wile on the car. One reason for the change is that I've decided to permanently attach the lower rockers to the front and rear fenders, and fill in the gaps, for a smooth look. also, I've had some trouble with bondo cracking at the upper B piller joint each time the rear clip is removed and replaced on the car, so painting it wile installed seems like a better idea today .
Wile I had the front clip setting on the car doing preliminary checks, I found that the hood opening is almost 1/4" too wide on each side, so it will be necessary to epoxy a strip of fiberglass onto each side of the hood and fill/sand for an acceptable gap...... I'm getting ahead of myself however as that may still be a few chapters down the road......


<to be continued>

[This message has been edited by Russ544 (edited 07-07-2009).]

IP: Logged

Previous Page | Next Page

This topic is 14 pages long:  1   2   3   4   5   6   7   8   9   10   11   12   13   14
next newest topic | next oldest topic

All times are ET (US)

Post New Topic  Post A Reply
Hop to:

Contact Us | Back To Main Page

Advertizing on PFF | Fiero Parts Vendors
PFF Merchandise | Fiero Gallery | Ogre's Cave
Real-Time Chat | Fiero Related Auctions on eBay



Copyright (c) 1999, C. Pennock
