What is ALDLView?

Waaaaay back in 2003, I got myself WinALDL and didn't want to mess with Excel just to view the captured data. So I wrote a little program that can graphically view data captured with WinALDL. For some reason, a few days ago I decided it was time to update it and add new functions. I also wanted to make it Vista compatible. So here it is.

The software is provided as-is, so it has no manual, nor a help file. Just play around with it a bit, it's pretty self-explanatory. You do need some data captured with WinALDL though. If you encounter any bugs, please let me know (in this thread) so I can correct them.

The latest version is v0.3-2 and you can get it here: ALDLView v0.3-2 (Win98, Win98SE, XP, Vista)
