Poly Suspension Upgrade (all pics) by MulletproofMonk
Started on: 09-04-2008 09:56 AM
Replies: 137 (19450 views)
Last post by: Dennis LaGrua on 10-02-2016 08:40 PM
MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 09:56 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post

Well, I wanted to do a Poly upgrade on my 87 GT. Lots of people here have posts with what to do... but then only have a picture of the before and after. I'm a picture kind of guy or show me and I can duplicate it after that. Now that I have done the upgrade, the text makes more sense. So, Madess helped me with the upgrade and we took pictures of everything. Maybe this will help someone like me... Sorry for all those on dialup...

-Brian

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 09:57 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post

84-87 Rear Poly Bushings


84-87 Rear Torque Specs from Ryan's excellent site: http://www.gmtuners.com/fil...7_Fiero_TQ_Specs.pdf


Dogbone



84-87 Rear Poly Suspension Upgrade


[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 09:58 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post











UPDATE 5/9/13
Here is a better way to remove the bushing, build a bushing removal tool so you don't have to inhale toxins.

[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:00 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post







UPDATE link on 5/23/13
Install that Dodgerunner belt tensioner while the control arm is out to give you more room to work.







UPDATE link 5/23/13
Here is a faster way to remove the rear control arm.

[This message has been edited by MulletproofMonk (edited 09-01-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:01 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post

84-87 Front Poly Bushings


84-87 Front Torque Specs from Ryan's excellent site:


UPDATE 5/21/13
Build one of these to keep track of your nuts and bolts...

84-87 Front Poly Suspension Upgrade

Sway bar 13mm
Tie Rod 17mm


Brake Caliper bolts T-50
Lower shock 15mm


Upper shock 13mm


[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

whodeanie
Member

Posts: 3819
From: woodstock,Ga.,USA
Registered: Jan 2008


Feedback score:    (14)
Leave feedback





Total ratings: 119
Rate this member

Report this Post09-04-2008 10:01 AM Click Here to See the Profile for whodeanieClick Here to visit whodeanie's HomePageClick Here to Email whodeanieSend a Private Message to whodeanieEdit/Delete MessageReply w/QuoteDirect Link to This Post

Nice step by step post.
sometimes it hard to understand without seeing it.

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:02 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post



Brake hose 10mm


Guessing there could be a difference in sizes...

Upper Control Arm 18mm


Upper Control Arm Ball Joint 17mm


Since that first time I have been using Rodney Dickman's Fiero Balljoint Separator Tool and it is worth the money.


[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:03 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post





UPDATE 5/9/13
Here is a better way to remove the bushing, build a bushing removal tool so you don't have to inhale toxins.


UPDATE 5/21/13
Build one of these to help press your bushings in...



Tie Rod 17mm


Lower Control Arm Ball Joint 19mm

[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:04 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post





**** WARNING 5/30/13 ****
I decided to make the spring pop out without restraints...

Lower Control Arm bolts 18mm
Sway bar 13mm


UPDATE 10/17/11
The front lower control arm bolt is going to be tight to the rack...
Removing the rack gave me extra clearance on the install but it isn't required...


UPDATE 5/21/13
Build one of these to help press your bushings in...


[This message has been edited by MulletproofMonk (edited 05-30-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:06 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post











UPDATE 7/16/13
So, here is something that I noticed about installing the front bolt on the front lower control arm...
Just a note, the replacement Sway Bar bolt was 14mm

[This message has been edited by MulletproofMonk (edited 07-16-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:07 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post

Note that the swaybar has the flat end on the drivers side and the round end on the passenger side.









[This message has been edited by MulletproofMonk (edited 05-30-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:08 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post

88 Rear Poly Bushings

[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:14 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post

88 Front Poly Bushings

[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

Hudini
Member

Posts: 7225
From: Shanghai, China
Registered: Feb 2006


Feedback score: N/A
Leave feedback





Total ratings: 153
Rate this member

Report this Post09-04-2008 10:17 AM Click Here to See the Profile for HudiniClick Here to Email HudiniSend a Private Message to HudiniEdit/Delete MessageReply w/QuoteDirect Link to This Post

Awesome write up and pics. Did you tighten everything up with the suspension hanging or with it compressed?

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 10:21 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post

EDIT: Condensing to add space for 88 poly...

whodeanie, how did you sneak in there? I thought I could get it all posted... =)

I should also thank Modat5 for helping.

I'll try to resize those ones that you have to click on so they show up...

-Brian


Well, that depends... The first time or the second when I got the caps cut down... =)
We tightened up the arms and torqued them first. Then as we started adding parts (some you will feel go together) we torqued them.

-Brian

[This message has been edited by MulletproofMonk (edited 05-23-2013).]

IP: Logged

Hudini
Member

Posts: 7225
From: Shanghai, China
Registered: Feb 2006


Feedback score: N/A
Leave feedback





Total ratings: 153
Rate this member

Report this Post09-04-2008 10:27 AM Click Here to See the Profile for HudiniClick Here to Email HudiniSend a Private Message to HudiniEdit/Delete MessageReply w/QuoteDirect Link to This Post

I asked because I had read you are *supposed* to torque it down with the weight of the car on the suspension. I simply let the car rest on the jack (under the lower ball joint) so as to simulate the wheel in place. Don't really know what difference it makes with poly.

IP: Logged

Fosgatecavy98
Member

Posts: 2966
From: GL,MI
Registered: Jul 2005


Feedback score: (2)
Leave feedback

Rate this member

Report this Post09-04-2008 10:48 AM Click Here to See the Profile for Fosgatecavy98Click Here to Email Fosgatecavy98Send a Private Message to Fosgatecavy98Edit/Delete MessageReply w/QuoteDirect Link to This Post

I'll add you can also cut the old rubber out with a saw-zaw. Lots of lets stink (still some tho)

I cant believe you didnt have any huge problems, I had all sorts of issues just doing the rear tie-rods and rear control arms, I still have yet to do the front :-(

IP: Logged

NW-Fiero
Member

Posts: 441
From: Pierce County - WA
Registered: Aug 2008


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-04-2008 10:57 AM Click Here to See the Profile for NW-FieroSend a Private Message to NW-FieroEdit/Delete MessageReply w/QuoteDirect Link to This Post

Did I miss the install of the Trans , Engine and Cradle Mounts......Red is good!
------------------
Mark
In the Great Northwest!

[This message has been edited by NW-Fiero (edited 09-04-2008).]

IP: Logged

whodeanie
Member

Posts: 3819
From: woodstock,Ga.,USA
Registered: Jan 2008


Feedback score:    (14)
Leave feedback





Total ratings: 119
Rate this member

Report this Post09-04-2008 11:00 AM Click Here to See the Profile for whodeanieClick Here to visit whodeanie's HomePageClick Here to Email whodeanieSend a Private Message to whodeanieEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by MulletproofMonk:

whodeanie, how did you sneak in there? I thought I could get it all posted... =)

I should also thank Modat for helping.

I'll try to resize those ones that you have to click on so they show up...

-Brian


just luckie I guess.
I just did the same thing on my 88 about 4 mounths ago plus the poly motor and trans mounts also (that was fun -- NOT!)
have you had the alignment done yet? mine were so bad that when I did the poly the rear wheels were all out of wack.
now it drives like a slotcar. then I went and tore the body off to do other mods so I have not driven it since

IP: Logged

Modat5
Member

Posts: 104
From: Dayton, OH.
Registered: Mar 2005


Feedback score: (1)
Leave feedback

Rate this member

Report this Post09-04-2008 12:54 PM Click Here to See the Profile for Modat5Send a Private Message to Modat5Edit/Delete MessageReply w/QuoteDirect Link to This Post

Nice job Brian.

Having helped on two of these now, I personally think the hardest part is removing and then
re-installing the springs....

Matt

88gt
88formula (fixing up to sell)
Dayton, OH

IP: Logged

americasfuture2k
Member

Posts: 7131
From: Edmond, Oklahoma
Registered: Jan 2006


Feedback score: (3)
Leave feedback





Total ratings: 106
Rate this member

Report this Post09-04-2008 01:25 PM Click Here to See the Profile for americasfuture2kSend a Private Message to americasfuture2kEdit/Delete MessageReply w/QuoteDirect Link to This Post

wow, that rotor looks outstanding!

------------------
1987 Fiero GT built by my brother, merlot566jka, 3500 LX9 from 06 Malibu, WOT-TECH.com 1280 grind stage 3 cam, LS6 valve springs, 1227730 ECM conversion, Darrel Morse solid aluminum cradle mounts, Truleo headers modified to fit the 3500, 36# inectors, 70mm 4.3 throttle body adapted to 3500 intake, ported heads, upper and lower intakes, lightly polished, tcemotorsports.com crank trigger wheel, CenterForce dual friction clutch, Flowtech Afterburner muffler, 2.5" piping, cat deleted, EGR deleted, SinisterPerformance tuning, C6 Corvette exhaust tips. projected to be 35 MPG with a guesstimate of 250 hp to the wheels

IP: Logged

FieroGeneral
Member

Posts: 92
From: Norway
Registered: Oct 2007


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-04-2008 01:40 PM Click Here to See the Profile for FieroGeneralSend a Private Message to FieroGeneralEdit/Delete MessageReply w/QuoteDirect Link to This Post

A + from me...Good writeup!

IP: Logged

Austrian Import
Member

Posts: 3919
From: Monterey, CA
Registered: Feb 2007


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-04-2008 01:54 PM Click Here to See the Profile for Austrian ImportClick Here to Email Austrian ImportSend a Private Message to Austrian ImportEdit/Delete MessageReply w/QuoteDirect Link to This Post

MulletproofMonk, thank you. I really appreciate threads with step-by-step pics.
Too many threads just have before and after, or are very stingy on pics.

Thanks for being detailed.

-Max

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 02:02 PM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by NW-Fiero:

Did I miss the install of the Trans , Engine and Cradle Mounts......Red is good!


We are also doing the Grand Am brake upgrade and I blew my little 5 gallon compressor up shaving the caliper brackets from 21mm to 18mm. I just got a 60 gallon compressor so I hope to cut those bolts out holding the cradle bushings in the front... When I do it I will post some pictures. Doing the cradle bushings seems a lot more straight forward to me. I didn't buy any trans, engine or cradle mounts so I don't have any pics...

-Brian

IP: Logged

crab daddy
Member

Posts: 119
From: Attleboro, MA
Registered: Feb 2007


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-04-2008 04:31 PM Click Here to See the Profile for crab daddyClick Here to Email crab daddySend a Private Message to crab daddyEdit/Delete MessageReply w/QuoteDirect Link to This Post

Excellet write up!

------------------
86 Fiero GT, 99 GTP (L67 swap will begin soon)
12.466 @ 114.15 INTENSE S1X/ZZP IC/TOG Headers

IP: Logged

Steven Snyder
Member

Posts: 3309
From: Los Angeles, CA
Registered: Mar 2004


Feedback score: (2)
Leave feedback





Total ratings: 106
Rate this member

Report this Post09-04-2008 08:13 PM Click Here to See the Profile for Steven SnyderClick Here to visit Steven Snyder's HomePageClick Here to Email Steven SnyderSend a Private Message to Steven SnyderEdit/Delete MessageReply w/QuoteDirect Link to This Post

The things you are calling "ball joint bushings" are dust boots. They are designed to keep the grease in and the dust out. The polyurethane ones don't really perform either function very well, and you shouldn't use them. Even if the rubber boot has a small tear it works better than the polyurethane covers.

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-04-2008 08:45 PM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Steven Snyder:
The things you are calling "ball joint bushings" are dust boots.


People have told me different things in their writeups, that is why I like pictures to see what people did. You could call it a tea cup and I can match the picture to the item on my (garage) floor.


quote
Originally posted by Steven Snyder:
The polyurethane ones don't really perform either function very well, and you shouldn't use them. Even if the rubber boot has a small tear it works better than the polyurethane covers.


My build thread is not what you should do, what you should use, it is simply what I did and how we did it. I happened to buy everything there on eBay for $100.00 (minus the dogbone and cradle bushings).

-Brian

[This message has been edited by MulletproofMonk (edited 09-05-2008).]

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-05-2008 06:36 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by americasfuture2k:

wow, that rotor looks outstanding!



Now that I had time to think about it, maybe I should post those in the mall...
I know that if it's cheap enough someone will buy it... =)
I'll probably have them turned down for the next brake upgrade.

-Brian

IP: Logged

Back On Holiday
Member

Posts: 6238
From: Downingtown, PA
Registered: Jul 2001


Feedback score:    (17)
Leave feedback





Total ratings: 154
Rate this member

Report this Post09-05-2008 07:21 AM Click Here to See the Profile for Back On HolidayClick Here to Email Back On HolidaySend a Private Message to Back On HolidayEdit/Delete MessageReply w/QuoteDirect Link to This Post

Good writeup, skimmed through it but gave you a + !

IP: Logged

USFiero
Member

Posts: 4770
From: West Palm Beach
Registered: Mar 2002


Feedback score: N/A
Leave feedback





Total ratings: 108
Rate this member

Report this Post09-05-2008 08:50 AM Click Here to See the Profile for USFieroSend a Private Message to USFieroEdit/Delete MessageReply w/QuoteDirect Link to This Post

I agree on the covers for the ball joints, they don't seal well. All the trouble you went through, and you didn't replace your ball joints? Especially the lower fronts? You reall, really, really want to replace those.

------------------
John DuRette
Custom 85 SE/86 GT
"Kinda makes you nostalgic for a Members Only jacket"

IP: Logged

MulletproofMonk
Member

Posts: 2844
From: Dayton, OH (Bellbrook, OH 45305)
Registered: Oct 2005


Feedback score:    (49)
Leave feedback





Total ratings: 77
Rate this member

Report this Post09-05-2008 09:02 AM Click Here to See the Profile for MulletproofMonkClick Here to visit MulletproofMonk's HomePageSend a Private Message to MulletproofMonkEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by USFiero:

All the trouble you went through, and you didn't replace your ball joints? Especially the lower fronts? You reall, really, really want to replace those.



No, my ball joints are all in great shape. The car only has about 70k miles and has that surface rust because it was parked so long without moving...

-Brian

IP: Logged

Blacktree
Member

Posts: 19100
From: Central Florida
Registered: Dec 2001


Feedback score:    (9)
Leave feedback





Total ratings: 341
Rate this member

Report this Post09-05-2008 11:13 AM Click Here to See the Profile for BlacktreeClick Here to visit Blacktree's HomePageClick Here to Email BlacktreeSend a Private Message to BlacktreeEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Hudini: I asked because I had read you are *supposed* to torque it down with the weight of the car on the suspension... Don't really know what difference it makes with poly.

With urethane bushings, you don't have to worry about that.

IP: Logged

Jeckel
Member

Posts: 113
From: Nampa, ID USA
Registered: Mar 2008


Feedback score: (1)
Leave feedback

Rate this member

Report this Post09-05-2008 01:26 PM Click Here to See the Profile for JeckelClick Here to Email JeckelSend a Private Message to JeckelEdit/Delete MessageReply w/QuoteDirect Link to This Post

This is a great write up. I need pictures to go from as well. Are you going to post pics of your brake upgrade too?

IP: Logged

MordacP
Member

Posts: 1300
From: Clovis, California, US
Registered: Sep 2007


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-05-2008 01:36 PM Click Here to See the Profile for MordacPClick Here to Email MordacPSend a Private Message to MordacPEdit/Delete MessageReply w/QuoteDirect Link to This Post

This is a great write up. I'll probably have to refer to this when I polyurethane-ize my suspension.

PS, I hope you plan on doing ALOT more before you drive the car. Dont have lots of confidence in those rotors.

IP: Logged

katatak
Member

Posts: 7135
From: Omaha, NE USA
Registered: Apr 2008


Feedback score:    (8)
Leave feedback





Total ratings: 83
Rate this member

Report this Post09-05-2008 02:46 PM Click Here to See the Profile for katatakSend a Private Message to katatakEdit/Delete MessageReply w/QuoteDirect Link to This Post

Great Write up.... In the process of doing this on my 86. I tried a couple different ways to remove the old cradle and a arm bushings. All of which worked. This is what worked for me:

I took a 1/4" bit in my cordless drill and started to drill along side the inner steel tube (bolt tube). The drill bit pulled itself into the rubber but also would rotate around the outside of the steel tube breaking it free from the rubber. As I pulled the bit back out, it pulled the tube out too. I had to tap it out the rest of the way with a punch. At this point, I was going to burn it out but when I went to light the torch, empty! So I took my sawsall and made several cuts in the rubber from the inside out to the cradle. Then, ran the sawsall around the outside of the rubber and pushed the pieces of the bushing out. I still had to go get a refill and finish burning what was left of the bushing. Of course the first one took the longest as I was "learning" the rest went very quick and I did not have burn that much rubber. In the long run, I used a combination of others ideas and it worked well. I even gave a hole saw a try. It works to but you have to have a deep one so that you can cut clear through the bushing. I have 2 a arms left to do. I will try and take pics for an update.

Pat

IP: Logged

NW-Fiero
Member

Posts: 441
From: Pierce County - WA
Registered: Aug 2008


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-05-2008 02:59 PM Click Here to See the Profile for NW-FieroSend a Private Message to NW-FieroEdit/Delete MessageReply w/QuoteDirect Link to This Post

When I burned all my bushings out my neighbors were not impressed with the smoke or smell. But what the heck... they don't know how to change oil either.......

------------------
Mark
In the Great Northwest!

IP: Logged

theogre
Member

Posts: 26857
From: USA
Registered: Mar 99


Feedback score: N/A
Leave feedback





Total ratings: 531
Rate this member

Report this Post09-06-2008 03:46 PM Click Here to See the Profile for theogreClick Here to visit theogre's HomePageSend a Private Message to theogreEdit/Delete MessageReply w/QuoteDirect Link to This Post

1. Polly joint covers are crap. You get far less protection as they do not seal anywhere near as well as the original ones. (Leaving out torn ones for now...)

They will let in dirt and water. If you hit them with a pressure washer, you can wash out the lube and and drive water/dirt into the joint so deep you never get it out.

The OEM type have a reinforced hole for the joint stem and a spring in the bottom to keep the big end shut. The major reason that these fail isn't age but morons with grease guns, especially power grease guns, that force them so full they cannot move properly. That's when they don't burst them when adding grease.

When rubber covers look like balloons, you've got way bloody too far much grease in them. You have to let some out. That is done by using a bit of dull metal, a small screwdriver usually works, to shift the small end so that grease can get out. Many after market ones that come on replacement joints are formed to have an easier escape path here than allot of factory ones had. Even then sometimes you've got to slip something between the top of the cover and whatever so that grease can get out.

2. Never split a joint you intend to reuse with a fork. Besides trashing the cover, you very often damage the joint itself that way.

3. Now that you're fairly stuck with poly covers, make sure you check the grease frequently. Make sure you use a grease that is hard to wash out. This is on top of the regular greasing poly bushings often need.

------------------
Dr. Ian Malcolm: Yeah, but your scientists were so preoccupied with whether or not they could, they didn't stop to think if they should.
(Jurassic Park)


The Ogre's Fiero Cave (It's also at the top of every forum page...)

[This message has been edited by theogre (edited 09-06-2008).]

IP: Logged

Steven Snyder
Member

Posts: 3309
From: Los Angeles, CA
Registered: Mar 2004


Feedback score: (2)
Leave feedback





Total ratings: 106
Rate this member

Report this Post09-06-2008 04:23 PM Click Here to See the Profile for Steven SnyderClick Here to visit Steven Snyder's HomePageClick Here to Email Steven SnyderSend a Private Message to Steven SnyderEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by MulletproofMonk:
My build thread is not what you should do, what you should use, it is simply what I did and how we did it. I happened to buy everything there on eBay for $100.00 (minus the dogbone and cradle bushings).


A lot of people are going to end up using your thread as a guide, so it's important that they are aware of the problem.

See Ogre's post above mine for a more detailed explanation of why the polyurethane dust boots should not be used.

IP: Logged

Fierology
Member

Posts: 1187
From: Texas
Registered: Dec 2006


Feedback score: (3)
Leave feedback

Rate this member

Report this Post09-06-2008 04:39 PM Click Here to See the Profile for FierologySend a Private Message to FierologyEdit/Delete MessageReply w/QuoteDirect Link to This Post

ABOUT POLY DUST BOOTS:

I was told by I forget who that the polys work well on the tie rod ends. Do you guys agree? Should I use the rubber, or can I stick w/ poly? I haven't torqued it yet, I believe, so it should be easy to switch them out.

thanks
-Michael

------------------
"A guy know's he's in love when he loses interest in his car for a few days." -Tim Allen

He who dies with the most toys... still dies.


Check out my restoration!

IP: Logged

Steven Snyder
Member

Posts: 3309
From: Los Angeles, CA
Registered: Mar 2004


Feedback score: (2)
Leave feedback





Total ratings: 106
Rate this member

Report this Post09-08-2008 04:12 AM Click Here to See the Profile for Steven SnyderClick Here to visit Steven Snyder's HomePageClick Here to Email Steven SnyderSend a Private Message to Steven SnyderEdit/Delete MessageReply w/QuoteDirect Link to This Post


quote
Originally posted by Fierology:

ABOUT POLY DUST BOOTS:

I was told by I forget who that the polys work well on the tie rod ends. Do you guys agree? Should I use the rubber, or can I stick w/ poly? I haven't torqued it yet, I believe, so it should be easy to switch them out.



I would use the rubber ones as long as they aren't badly torn. A little hole would probably be alright; once you fill it with grease some will squeeze out of the hole and keep the dust out...

IP: Logged

Previous Page | Next Page

This topic is 4 pages long:  1   2   3   4
next newest topic | next oldest topic

All times are ET (US)

Post New Topic  Post A Reply
Hop to:

Contact Us | Back To Main Page

Advertizing on PFF | Fiero Parts Vendors
PFF Merchandise | Fiero Gallery | Ogre's Cave
Real-Time Chat | Fiero Related Auctions on eBay



Copyright (c) 1999, C. Pennock
