Converting fiero from manual to automatic, need help by jjd2296
Started on: 11-19-2021 04:23 PM
Replies: 23 (512 views)
Last post by: rbell2915 on 11-30-2024 07:59 PM
jjd2296
Member
Posts: 1470
From: toronto ON
Registered: Jan 2016


Feedback score:    (8)
Leave feedback

Rate this member

Report this Post11-19-2021 04:23 PM Click Here to See the Profile for jjd2296Send a Private Message to jjd2296Edit/Delete MessageReply w/QuoteDirect Link to This Post
I know, I know, you don't have to ask why. its for a build im doing for my dad, he doesn't drive manual. has anyone done this before? is it more difficult then doing a auto to manual swap?
IP: Logged
PFF
System Bot
Dennis LaGrua
Member
Posts: 15882
From: Hillsborough, NJ U.S.A.
Registered: May 2000


Feedback score:    (13)
Leave feedback





Total ratings: 328
Rate this member

Report this Post11-19-2021 05:48 PM Click Here to See the Profile for Dennis LaGruaSend a Private Message to Dennis LaGruaEdit/Delete MessageReply w/QuoteDirect Link to This Post
I've done them. You will need the transmission w Torque converter, CV axles, brackets/mounts, flexplate (for model year), TC bolts (high grade), Trans mounting bolts, shifter, trans selector switch ( rewire here), larger brake pedal, oil cooler/radiator, hard trans lines (you can make them), oil cooler hose, clamps and a wire to the ECM to activate the TC clutch. Finally you will need the ECM for the automatic or at the very least a chip with the automatic program on it. It is not a real hard job but I would not call it easy. The car must be lifted and the cradle dropped. Working alone, I would estimate 20 hrs of labor. Please work carefully. We already lost a member here this year from a car falling on him.

------------------
" THE BLACK PARALYZER" -87GT 3800SC Series III engine, custom ZZP /Frozen Boost Intercooler setup, 3.4" Pulley, Northstar TB, LS1 MAF, 3" Spintech/Hedman Exhaust, P-log Manifold, Autolite 104's, MSD wires, Custom CAI, 4T65eHD w. custom axles, Champion Radiator, S10 Brake Booster, HP Tuners VCM Suite.
"THE COLUSSUS"
87GT - ALL OUT 3.4L Turbocharged engine, Garrett Hybrid Turbo, MSD ign., modified TH125H
" ON THE LOOSE WITHOUT THE JUICE "

IP: Logged
jjd2296
Member
Posts: 1470
From: toronto ON
Registered: Jan 2016


Feedback score:    (8)
Leave feedback

Rate this member

Report this Post11-20-2021 08:16 AM Click Here to See the Profile for jjd2296Send a Private Message to jjd2296Edit/Delete MessageReply w/QuoteDirect Link to This Post
Thanks Denis. Yes I’ll be safe I have access to a shop with a lift.
IP: Logged
pmbrunelle
Member
Posts: 4614
From: Grand-Mère, Québec
Registered: Sep 2008


Feedback score: N/A
Leave feedback





Total ratings: 63
Rate this member

Report this Post11-20-2021 09:34 AM Click Here to See the Profile for pmbrunelleSend a Private Message to pmbrunelleEdit/Delete MessageReply w/QuoteDirect Link to This Post
There is also the automatic steering column (and the interlock cable); this one has the capability to block removal of the key unless the shifter is in Park.

[This message has been edited by pmbrunelle (edited 11-20-2021).]

IP: Logged
jjd2296
Member
Posts: 1470
From: toronto ON
Registered: Jan 2016


Feedback score:    (8)
Leave feedback

Rate this member

Report this Post11-21-2021 12:01 PM Click Here to See the Profile for jjd2296Send a Private Message to jjd2296Edit/Delete MessageReply w/QuoteDirect Link to This Post
I have the steering wheel and cable already
IP: Logged
Dennis LaGrua
Member
Posts: 15882
From: Hillsborough, NJ U.S.A.
Registered: May 2000


Feedback score:    (13)
Leave feedback





Total ratings: 328
Rate this member

Report this Post11-21-2021 01:50 PM Click Here to See the Profile for Dennis LaGruaSend a Private Message to Dennis LaGruaEdit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by jjd2296:

I have the steering wheel and cable already


On the recent conversion that I did the column was left alone. Saw no reason to change steering columns and add more work to the process. The manual cars already have a locking steering wheel. The whole lockout system is just feel good security . Its not going to stop the professional.

------------------
" THE BLACK PARALYZER" -87GT 3800SC Series III engine, custom ZZP /Frozen Boost Intercooler setup, 3.4" Pulley, Northstar TB, LS1 MAF, 3" Spintech/Hedman Exhaust, P-log Manifold, Autolite 104's, MSD wires, Custom CAI, 4T65eHD w. custom axles, Champion Radiator, S10 Brake Booster, HP Tuners VCM Suite.
"THE COLUSSUS"
87GT - ALL OUT 3.4L Turbocharged engine, Garrett Hybrid Turbo, MSD ign., modified TH125H
" ON THE LOOSE WITHOUT THE JUICE "

[This message has been edited by Dennis LaGrua (edited 11-26-2021).]

IP: Logged
jjd2296
Member
Posts: 1470
From: toronto ON
Registered: Jan 2016


Feedback score:    (8)
Leave feedback

Rate this member

Report this Post11-24-2021 01:52 PM Click Here to See the Profile for jjd2296Send a Private Message to jjd2296Edit/Delete MessageReply w/QuoteDirect Link to This Post
I have the steering wheel and cable already
IP: Logged
ZaraSpOOk
Member
Posts: 256
From: Rosemount, MN
Registered: Sep 2010


Feedback score: N/A
Leave feedback

Rate this member

Report this Post11-29-2021 06:02 PM Click Here to See the Profile for ZaraSpOOkSend a Private Message to ZaraSpOOkEdit/Delete MessageReply w/QuoteDirect Link to This Post
just wanted to say cograts to you, all the pain in the butt clutch problems will be a thing of the past
And as a bonus you likely caused a lot of guys who did (or wanted to) do a auto to manual swap to say "SOMOFABITCH!"
so what are you doing with that highly desirable (sic) Getrag (should have been called Getrags, one rag has never been enough)

[This message has been edited by ZaraSpOOk (edited 11-29-2021).]

IP: Logged
Dennis LaGrua
Member
Posts: 15882
From: Hillsborough, NJ U.S.A.
Registered: May 2000


Feedback score:    (13)
Leave feedback





Total ratings: 328
Rate this member

Report this Post11-29-2021 08:39 PM Click Here to See the Profile for Dennis LaGruaSend a Private Message to Dennis LaGruaEdit/Delete MessageReply w/QuoteDirect Link to This Post
I've been an automatic man for many years going back to my drag racing days. No human can shift a Fiero as fast as an automatic can but the stick guys say shifting through the gears is fun, that is until you get stuck in stop and go traffic for an hour..

------------------
" THE BLACK PARALYZER" -87GT 3800SC Series III engine, custom ZZP /Frozen Boost Intercooler setup, 3.4" Pulley, Northstar TB, LS1 MAF, 3" Spintech/Hedman Exhaust, P-log Manifold, Autolite 104's, MSD wires, Custom CAI, 4T65eHD w. custom axles, Champion Radiator, S10 Brake Booster, HP Tuners VCM Suite.
"THE COLUSSUS"
87GT - ALL OUT 3.4L Turbocharged engine, Garrett Hybrid Turbo, MSD ign., modified TH125H
" ON THE LOOSE WITHOUT THE JUICE "

IP: Logged
ZaraSpOOk
Member
Posts: 256
From: Rosemount, MN
Registered: Sep 2010


Feedback score: N/A
Leave feedback

Rate this member

Report this Post11-30-2021 06:54 PM Click Here to See the Profile for ZaraSpOOkSend a Private Message to ZaraSpOOkEdit/Delete MessageReply w/QuoteDirect Link to This Post
All my vehicles I've owned since 1972 (Ford Mustang 1966) have had manual transmissions, other than replace the Mustang's tranny with a rebuilt (why I only had to pay $200 for a fairly pristine one) I've never ever had to bleed , replace a clutch, or do any tranny work EXCEPT for the highly desirable Getrags

My Vette has 6 gears, a genuine pain in rush hour which is why I almost never commute with it, I did finally get an SUV with an a CVT and paddles which I almost never use, the exception being to use engine braking in winter on occasion rather than the brakes

today a manual transmission is like a corded phone or a VCR
if I bought another Vette, it certainly would not have a manual transmission

[This message has been edited by ZaraSpOOk (edited 11-30-2021).]

IP: Logged
Patrick
Member
Posts: 38659
From: Vancouver, British Columbia, Canada
Registered: Apr 99


Feedback score: (1)
Leave feedback





Total ratings: 466
Rate this member

Report this Post11-30-2021 07:02 PM Click Here to See the Profile for PatrickSend a Private Message to PatrickEdit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by ZaraSpOOk:

today a manual transmission is like a corded phone...


Love my corded phone. Much better sound quality than a cell phone, and no "network" issues.

And oh yeah, automatics suck.
IP: Logged
PFF
System Bot
pmbrunelle
Member
Posts: 4614
From: Grand-Mère, Québec
Registered: Sep 2008


Feedback score: N/A
Leave feedback





Total ratings: 63
Rate this member

Report this Post11-30-2021 07:27 PM Click Here to See the Profile for pmbrunelleSend a Private Message to pmbrunelleEdit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by Patrick:
Love my corded phone. Much better sound quality than a cell phone, and no "network" issues.


I don't think that cellphones must inherently have worse sound quality (with 21st century human knowledge, we should be able to best our predecessors)... though I do think that today's consumers expect low prices and disregard quality. Companies optimize between price and quality to align with customer expectations.

How is it that a 1984 Fiero ECM can still run its engine acceptably well on its original chip, while a brand-new smartphone is released with flawed software and needs constant software updates? I blame the consumer.

[This message has been edited by pmbrunelle (edited 11-30-2021).]

IP: Logged
Dennis LaGrua
Member
Posts: 15882
From: Hillsborough, NJ U.S.A.
Registered: May 2000


Feedback score:    (13)
Leave feedback





Total ratings: 328
Rate this member

Report this Post11-30-2021 07:45 PM Click Here to See the Profile for Dennis LaGruaSend a Private Message to Dennis LaGruaEdit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by Patrick:

And oh yeah, automatics suck.

I wish that we were able to race so that I could prove you wrong. I can reprogram my PCM to control the 4T65eHD for any shift point and any style of driving. If you are referring to the TH125; a three speed auto is certainly not ideal but many have had success racing with a modified one.


------------------
" THE BLACK PARALYZER" -87GT 3800SC Series III engine, custom ZZP /Frozen Boost Intercooler setup, 3.4" Pulley, Northstar TB, LS1 MAF, 3" Spintech/Hedman Exhaust, P-log Manifold, Autolite 104's, MSD wires, Custom CAI, 4T65eHD w. custom axles, Champion Radiator, S10 Brake Booster, HP Tuners VCM Suite.
"THE COLUSSUS"
87GT - ALL OUT 3.4L Turbocharged engine, Garrett Hybrid Turbo, MSD ign., modified TH125H
" ON THE LOOSE WITHOUT THE JUICE "

IP: Logged
Patrick
Member
Posts: 38659
From: Vancouver, British Columbia, Canada
Registered: Apr 99


Feedback score: (1)
Leave feedback





Total ratings: 466
Rate this member

Report this Post11-30-2021 08:49 PM Click Here to See the Profile for PatrickSend a Private Message to PatrickEdit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by Dennis LaGrua:

I wish that we were able to race so that I could prove you wrong...


Dennis, my comment was a tease and made in fun... but with fun in mind, you'll never convince me that an automatic is more fun to drive than a manual. Sure, an automatic may make stop and go driving in heavy traffic more tolerable, but at any other time, a manual is much more enjoyable to drive.
IP: Logged
Patrick
Member
Posts: 38659
From: Vancouver, British Columbia, Canada
Registered: Apr 99


Feedback score: (1)
Leave feedback





Total ratings: 466
Rate this member

Report this Post11-30-2021 09:14 PM Click Here to See the Profile for PatrickSend a Private Message to PatrickEdit/Delete MessageReply w/QuoteDirect Link to This Post

Patrick

38659 posts
Member since Apr 99

quote
Originally posted by pmbrunelle:

I don't think that cellphones must inherently have worse sound quality (with 21st century human knowledge, we should be able to best our predecessors)... though I do think that today's consumers expect low prices and disregard quality.


It doesn't take listening to too many radio interviews with guests on their cell phones to realize how poor the sound quality compares to a landline. Even when the signal doesn't drop out entirely, often the vocals become totally distorted. Sure, in theory, modern technology can give us pristine sound/audio quality with cell phones... but in the real world, it actually leaves a lot to be desired.
IP: Logged
Larryinkc
Member
Posts: 705
From: Kansas City, MO USA
Registered: Nov 2012


Feedback score: (3)
Leave feedback

Rate this member

Report this Post11-30-2021 10:18 PM Click Here to See the Profile for LarryinkcSend a Private Message to LarryinkcEdit/Delete MessageReply w/QuoteDirect Link to This Post
In my world real cars have 2 doors and 3 pedals.

The Manual Gearbox Preservation Society

We are the guardians of a dying art. The purveyors of a craft born of necessity, but beloved for its spirit. We travel with purpose regardless of our destination. Every corner an opportunity for the perfect downshift, every stop a new starting line. We find joy in those fleeting moments between ratios; the crescendo of rpm, the gentle click of the gate, the building inertia in our chest as the drivetrain becomes whole again. We are the masters of our machines. We are The Manual Gearbox Preservation Society!


https://tmgps.org/
IP: Logged
Patrick
Member
Posts: 38659
From: Vancouver, British Columbia, Canada
Registered: Apr 99


Feedback score: (1)
Leave feedback





Total ratings: 466
Rate this member

Report this Post11-30-2021 11:10 PM Click Here to See the Profile for PatrickSend a Private Message to PatrickEdit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by Larryinkc:

The Manual Gearbox Preservation Society




IP: Logged
jjd2296
Member
Posts: 1470
From: toronto ON
Registered: Jan 2016


Feedback score:    (8)
Leave feedback

Rate this member

Report this Post04-21-2024 03:11 PM Click Here to See the Profile for jjd2296Send a Private Message to jjd2296Edit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by Dennis LaGrua:

I've done them. You will need the transmission w Torque converter, CV axles, brackets/mounts, flexplate (for model year), TC bolts (high grade), Trans mounting bolts, shifter, trans selector switch ( rewire here), larger brake pedal, oil cooler/radiator, hard trans lines (you can make them), oil cooler hose, clamps and a wire to the ECM to activate the TC clutch. Finally you will need the ECM for the automatic or at the very least a chip with the automatic program on it. It is not a real hard job but I would not call it easy. The car must be lifted and the cradle dropped. Working alone, I would estimate 20 hrs of labor. Please work carefully. We already lost a member here this year from a car falling on him.



when you say rewire for the trans selector switch? do you mean on the engine harness? if so I used a auto engine harness but didnt change the interior harness. the car is all done and just waiting to start it up. right now it doesnt start. I have power on the interior but only on the radio and HVAC, dash has no lights, turn key nothing happens. I did move the 12v power from A4 to E2 on the engine harness as I read that is required if you keep the manual c500 harness.

I believe I have something not connected right on the auto brake pedal that was installed? it had the 2 pedal switches on it when I got it so I just plugged them in thinking that's all that was needed. the original clutch safety switch was cut and the purple and yellow wires soldered together. I did install a auto steering column as well.

For those of you tech guys, have I missed something? I did notice that my ignition key will turn but when I go to turn it off it goes slightly past the point where it should stop to remove the key. when this happens the interior lights come back on as well. could my ignition switch on the steering column be bad? do I have the pedal connectors hooked up wrong?

one other thing, I converted to a gen 2 headlight wiring and module. I flip the headlight switch and the headlights go up perfectly, hit the switch again to put them down and nothing, not even a sound from the motors.

any tech help with pictures and directions would be great.
IP: Logged
olejoedad
Member
Posts: 19795
From: Clarendon Twp., MI
Registered: May 2004


Feedback score: (5)
Leave feedback





Total ratings: 207
Rate this member

Report this Post04-21-2024 07:07 PM Click Here to See the Profile for olejoedadSend a Private Message to olejoedadEdit/Delete MessageReply w/QuoteDirect Link to This Post
You aren't getting a start signal to the starter solenoid?

Try adjusting the neutral safety switch on the transmission.
IP: Logged
jjd2296
Member
Posts: 1470
From: toronto ON
Registered: Jan 2016


Feedback score:    (8)
Leave feedback

Rate this member

Report this Post04-22-2024 07:46 AM Click Here to See the Profile for jjd2296Send a Private Message to jjd2296Edit/Delete MessageReply w/QuoteDirect Link to This Post
Goss I didn’t set that to factory reset when I installed it. I’ll do that and see what happens.

IP: Logged
olejoedad
Member
Posts: 19795
From: Clarendon Twp., MI
Registered: May 2004


Feedback score: (5)
Leave feedback





Total ratings: 207
Rate this member

Report this Post04-22-2024 10:09 AM Click Here to See the Profile for olejoedadSend a Private Message to olejoedadEdit/Delete MessageReply w/QuoteDirect Link to This Post

quote
Originally posted by jjd2296:

Goss I didn’t set that to factory reset when I installed it. I’ll do that and see what happens.


Loosen the two bolts on the NSS, have someone hold the key in the START position, and rotate the NSS slightly until the starter kicks. The NSS will allow the START signal in PARK and NEUTRAL only.

Once you find that spot, put the shifter in REVERSE, key in the ON position, and check that the backup lights are on.

If everything works as it should, tighten the two bolts to secure the NSS in position.
IP: Logged
PFF
System Bot
richard in nc
Member
Posts: 450
From: charlotte nc
Registered: Jun 2023


Feedback score: N/A
Leave feedback

Rate this member

Report this Post04-22-2024 10:51 AM Click Here to See the Profile for richard in ncSend a Private Message to richard in ncEdit/Delete MessageReply w/QuoteDirect Link to This Post
https://www.youtube.com/watch?v=uFMcj3QD8vU its in this video.ignore the silly parts.good information.
IP: Logged
jjd2296
Member
Posts: 1470
From: toronto ON
Registered: Jan 2016


Feedback score:    (8)
Leave feedback

Rate this member

Report this Post04-23-2024 07:17 PM Click Here to See the Profile for jjd2296Send a Private Message to jjd2296Edit/Delete MessageReply w/QuoteDirect Link to This Post
Frig. I did a bunch of adjustments on the steering column Ignition switch and the NSS. At one point I got the starter to engage a couple times while fiddling with the shifter but I couldn’t get it in the right spot. Well I know it’s probably the nss adjustment or it’s bad. And now I k ow my starter needs adjustment as well as it’s just spinning and not cranking. I’ll leave it for another day now.
IP: Logged
rbell2915
Member
Posts: 1512
From: Kenly, NC
Registered: Mar 2013


Feedback score:    (10)
Leave feedback

Rate this member

Report this Post11-30-2024 07:59 PM Click Here to See the Profile for rbell2915Send a Private Message to rbell2915Edit/Delete MessageReply w/QuoteDirect Link to This Post
Did you get this completed?
IP: Logged
