  Delrin Bushings?

T H I S   I S   A N   A R C H I V E D   T O P I C


Email This Page to Someone! | Printable Version


Delrin Bushings? by Razor_Wing
Started on: 09-14-2003 10:25 AM
Replies: 7
Last post by: Razor_Wing on 09-14-2003 07:04 PM
Razor_Wing
Member
Posts: 1753
From: Blowing Rock, NC, USA
Registered: Apr 2003


Feedback score: N/A
Leave feedback





Total ratings: 71
Rate this member

Report this Post09-14-2003 10:25 AM Click Here to See the Profile for Razor_WingSend a Private Message to Razor_WingDirect Link to This Post
Well, I'm going to have to replace all my ball joints real soon, I'm going to get poly's (is there anywhere cheaper then fiero store?), but I think I want to replace the A arm bushings too, might as well. I want something higher performance. I know about Poly for them too, but west coast fiero (www.westcoastfiero.com) carries some that are caled "Delrin". Anyone have them? Are they good? How much better then poly are they??? Are they worth it? Thx guys!

------------------

www.freewebs.com/fierogti

"Go fast before you look fast"
<>{RazorWing}<>

IP: Logged
PFF
System Bot
Nashco
Member
Posts: 4144
From: Portland, OR
Registered: Dec 2000


Feedback score:    (8)
Leave feedback





Total ratings: 74
Rate this member

Report this Post09-14-2003 11:11 AM Click Here to See the Profile for NashcoClick Here to visit Nashco's HomePageSend a Private Message to NashcoDirect Link to This Post
You may also want to check out www.8shark.com - they have some UHMW (Ultra High Molecular Weight) bushings. UHMW is a great material that supposedly outlasts Delrin.

Going from rubber to poly has a very slightly noticeable increase in ride harshness, well worth the increased handling for me. Beware, though, the UHMW or Delrin bushings will increase ride harshness quite noticeably in comparison to your rubber bushings. The UHMW/Delrin bushings are really unnecessary for a daily driver...you wouldn't be able to tell the difference in handling between that and poly anywhere but on the racetrack.

Bryce
88 GT

IP: Logged
Will
Member
Posts: 14278
From: Where you least expect me
Registered: Jun 2000


Feedback score: (1)
Leave feedback





Total ratings: 237
Rate this member

Report this Post09-14-2003 01:01 PM Click Here to See the Profile for WillSend a Private Message to WillDirect Link to This Post
I don't like poly. Polyurethane is a sticky plastic that adds unnecessary friction to the suspension.

I made a set of delrin bushings a while back. I'm replacing them with UHMW now. Needless to say I think that UHMW is a better material for this application. However, UHMW is UMHW, and there are many varieties of delrin which may be more or less appropriate to suspension bushings. The variety I had at the (incorrect) clearances I was running did not do well.

I recommend 8shark's UHMW bushings. I haven't used his bushings though, as I'm making my own.

Another thing to consider is XL-UHMW. It has better NVH characteristics than regular UHMW, although it is quite hard to find.

------------------
'87 Fiero GT: Northstar, Getrag, TGP wheels, rear sway bar, rod end links, bushings, etc.

'90 Pontiac 6000 SE AWD: Leaking ABS unit fixed, load levelling rear suspension fixed, still slow

IP: Logged
Razor_Wing
Member
Posts: 1753
From: Blowing Rock, NC, USA
Registered: Apr 2003


Feedback score: N/A
Leave feedback





Total ratings: 71
Rate this member

Report this Post09-14-2003 01:05 PM Click Here to See the Profile for Razor_WingSend a Private Message to Razor_WingDirect Link to This Post
Thx! Ride comfort is'nt exactly something I care alot about, lol. How much of an improvement would I see from ruber to poly a arm bushings? Poly to that stuff (fromt the link you gave me)? ruber to that?

One semi off topc question, will I see any handeling change in the poly ball joints over the ruber? Is there anything like allunium ball joints or annything like that?

IP: Logged
Monster
Member
Posts: 281
From: Silver Spring, MD
Registered: Jan 2003


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-14-2003 04:27 PM Click Here to See the Profile for MonsterSend a Private Message to MonsterDirect Link to This Post
Razor_Wing - I think that the "Poly Ball Joints" that you're seeing in the kits are the ball joint boots not the ball joints themselves - Ball joints are typically all metal, although some have "self lubricating" nylon or other synthetic ball cups down inside.

I don't know of any real advantage to the poly boots for street use other than they look good. I think their main utility is in protecting the joint from damage by debris. Great for offroad.

Pretty much the same for the tie rod boots - the look good & provide some additional protection.

IP: Logged
Razor_Wing
Member
Posts: 1753
From: Blowing Rock, NC, USA
Registered: Apr 2003


Feedback score: N/A
Leave feedback





Total ratings: 71
Rate this member

Report this Post09-14-2003 05:24 PM Click Here to See the Profile for Razor_WingSend a Private Message to Razor_WingDirect Link to This Post

quote
Originally posted by Monster:

Razor_Wing - I think that the "Poly Ball Joints" that you're seeing in the kits are the ball joint boots not the ball joints themselves - Ball joints are typically all metal, although some have "self lubricating" nylon or other synthetic ball cups down inside.

I don't know of any real advantage to the poly boots for street use other than they look good. I think their main utility is in protecting the joint from damage by debris. Great for offroad.

Pretty much the same for the tie rod boots - the look good & provide some additional protection.

Lol, yeah, that just hit me! If my ball joints are bad, I need the actual ball joints, not just the poly "boots" don't I? lol. Are there any "high performance" ball joints or just factories? Where is the cheapest place to get them? How much?

IP: Logged
Monster
Member
Posts: 281
From: Silver Spring, MD
Registered: Jan 2003


Feedback score: N/A
Leave feedback

Rate this member

Report this Post09-14-2003 06:40 PM Click Here to See the Profile for MonsterSend a Private Message to MonsterDirect Link to This Post
Ah, now you understand why my forehead curves inward - DOH! <SLAP>. Realizing what I already knew.

For high quality & some adjustability, there's no beating the Moog Problem Solver ball joints. They're the best out there for OEM replacement IMHO. They should be available from any decent parts store. Just make sure that they're made by Moog.

IP: Logged
Razor_Wing
Member
Posts: 1753
From: Blowing Rock, NC, USA
Registered: Apr 2003


Feedback score: N/A
Leave feedback





Total ratings: 71
Rate this member

Report this Post09-14-2003 07:04 PM Click Here to See the Profile for Razor_WingSend a Private Message to Razor_WingDirect Link to This Post

quote
Originally posted by Monster:

Ah, now you understand why my forehead curves inward - DOH! <SLAP>. Realizing what I already knew.

For high quality & some adjustability, there's no beating the Moog Problem Solver ball joints. They're the best out there for OEM replacement IMHO. They should be available from any decent parts store. Just make sure that they're made by Moog.

Thx man! You get a plus .

------------------

www.freewebs.com/fierogti

"Go fast before you look fast"
<>{RazorWing}<>

IP: Logged
