Originally posted by josef644:

Is this photo of the Corvette gauges, or the Camero set?



Those are the Camaro gauges

Jscott1, not calling you out on the delay...mentioned you more so as you've been great to work with and wanted you to get the attention you deserve. It's people like you that truly make this forum a great place. I'm glad I had you do these for me as once I got involved, there was a lot I really didn't know how to do. Besides, it's left me more time this month to work on the Indy restoration.

Generally speaking, the corvette parts rundown will cost you something like this.

Dash, $100-150
Forward Console, $75-100
Rear Console w/ Lid, $50-75
Outer Gauge Surround, $25
Gauge Lens, $20
Driver's Knee Bolster and Glove Box, $50-100


So, it does add up, but if you find someone parting a car out local to you, you can probably half those prices as they're awkward to ship. I got most of the parts off of cars that I dismantled, etc. so it was cheaper for me.

BTW, those guages look way better than I expected. I paid like $35 for them on eBay, so they're pretty cheap. Of course, I have a dozen of the C5 clusters in stock that I'm selling for only $75-100...but again, I had no clue how to get them working in the car...
